Dymind DH76 Auto Hematology Analyzer

Tri-angle Laser scatter,chemical dye ,and flow cytometry; 5-part differentiation, 29 parameters; 1 3D scatter gram ,3 2D scatter grams and 3 histograms; Only 20ul sampling volume; Up to 80 samples per hour; 60 samples continously loading ; 3 counting modes: whole blood ,capillary blood and prediluted; up to 100,000 samples results can be stored; Bi-directional Lis connection.




  • Impedance method for WBC, RBC, PLT counting Cyanide-free reagent for Hemoglobin test Flow Cytometry (FCM), Semi-conductor Laser scatter, chemical dye method, independent Basophil channel.


  • WBC, Lym%, Lym#,Mon%, Mon#,Neu%, Neu#,Eos%, Eos#, Bas%, Bas#, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, PDW, MPV, PCT,and 4 research parameters P-LCC , P-LCR, LIC%, LIC#, ALY%, ALY# 1 3D and 3 2D 3 scatter grams and 3 histograms


  • Up to 80 samples per hour


  • Volume Whole Blood: 20ul Prediluted: 20ul

Test Mode



  • Carryover Repeatability Linearity WBC ≤0.5% ≤2.0% (4-15×109/L) 0.00-300×109/L RBC ≤0.5% ≤1.5% (3.5-6.0×1012/L) 0.00-8.5×1012/L HGB ≤0.6% ≤1.5% (110-180g/L) 0-250g/L PLT ≤1.0% ≤4.0% (150-500×109/L) 0.00-3000×109/L

Data Storage Capacity

  • Up to 100,000 results including numeric and graphical information


  • LAN port supports HL7 protocol

Operating Environment

  • Temperature: 15°C-30°C Humidity: 30-85% Air Pressure: 70-106 kPa

Dimension and Weight

  • 620mm(L) × 620mm(W) × 535mm(H)
