Bistos BT-500 Instant Infant Incubator

Description

Design and Protection Mechanism: Double-Walled Hood Configuration The Bistos BT-500 is a premium, double-walled infant incubator designed to create a thermo-neutral, humidity-controlled microenvironment for premature and low-birth-weight neonates, minimizing heat loss and infection risks in neonatal intensive care units (NICUs), delivery rooms, and pediatric transport. Constructed with a transparent, low-noise polycarbonate hood (acrylic option) that reduces radiant heat loss by 30% and acoustic exposure to <55 dB, it features a spacious bassinet (650 × 380 mm) with soft, adjustable tilting for Trendelenburg positioning. Safety interlocks include sensor failure alarms, over-temperature cutoffs, and a manual override for emergencies, ensuring compliance with ISO 80601-2-35 standards for neonatal thermoregulation and infection control.

Performance and Temperature/Humidity Control: Maintains air or skin temperature from 25–39°C (±0.3°C stability) with servo-control modes, coupled with humidity regulation from 30–95% (±5% accuracy) via ultrasonic nebulization for optimal skin hydration and respiratory support. The microprocessor-driven system uses dual PID algorithms to achieve <5-minute recovery after canopy openings, while the forced convection heater (500W) ensures uniform distribution (±0.5°C variance). Oxygen blending (21–50%, optional) supports hypoxic neonates, with real-time compensation for ambient fluctuations up to 32°C, promoting stable VLBW infant recovery.

Bassinet and Accessibility: The ergonomic bassinet tilts ±15° electrically for postural drainage and comfort, with a 360° swiveling base on lockable casters (100 mm) for seamless transport between rooms. The spacious interior (internal height 850 mm) accommodates up to 10 kg infants, with access ports (4 × 100 mm) for IV lines and monitoring without disrupting the environment. The integrated X-ray cassette tray (under-mattress) enables in-situ imaging, and the optional powerful lifting structure adjusts height from 850–1,500 mm for caregiver ergonomics.

User Interface and Operational Features: A vibrant 7-inch TFT color LCD displays air/skin temps, humidity, setpoints, trends (1–24 hours), and alarms in real-time, with multilingual support (up to 8 languages, including English and Chinese) and intuitive touch controls. Programmable modes include manual/servo/auto humidity, with 27 alarm events (e.g., high/low temp, power failure) featuring audible/visual/nurse call outputs. The integrated CCD camera streams live video to external monitors, while the optional Masimo SpO2 module provides SET®-accurate pulse oximetry (70–100%, ±2%).

Sterilization and Maintenance: The smooth, seamless hood and stainless steel base wipe down with 70% IPA or hypochlorite, with detachable panels for deep cleaning and autoclavable mattress covers (121°C). The self-diagnostic system runs at startup, flagging sensor drift or heater faults, while the maintenance-free servo heater and ultrasonic humidifier require quarterly filter changes. Annual calibration via USB ensures traceability, with a 2-year warranty on core components for uninterrupted NICU reliability.

Electrical and Environmental Specifications: Operates on AC 100–240V/50–60Hz at 600W, with surge protection and optional battery backup (2 hours) for transport. Designed for 10–35°C ambient and ≤80% RH, it includes EMI shielding (IEC 60601-1-2) to avoid interference with ventilators or monitors. Low power idle mode (<50W) supports energy-efficient 24/7 operation.

Dimensions and Installation Flexibility: Compact footprint of 1,024 × 690 × 1,354 mm (W × D × H) weighs 65 kg, with a swivel base for 90° turns and 4 casters for mobility. Requires 1 m² floor space; quick assembly in <30 minutes with no special tools, fitting standard NICU bays or mobile units.

• Throughput and Workflow: Handles continuous 24/7 monitoring for 5–10 neonates/shift, with <2-minute setup for transfers.
• Detection and Monitoring: Triple sensors (air, skin, humidity) with 0.01°C resolution; logs 7-day trends for audits.
• Detection Principle: Servo-controlled convection heating + ultrasonic humidification for stratified stability.
• Additional Features: Accurate ±10 g weighing scale; X-ray compatibility; nurse call integration; optional O2 blender.
• Data Storage: 1,000-hour internal memory for exports in CSV/PDF via USB.
• Patient Handling Modes: Supine/prone tilting; transport-ready with battery; compatible with CPAP/ventilators.
