Maccura F800 5-Part Auto Hematology Analyzer
The Maccura F800 is a premium 5-part hematology analyzer with CBC+DIFF+RET capabilities, delivering up to 100 tests/hour using 88 µL sample volume. Engineered for large labs, it leverages fluorescence staining + flow cytometry for precise WBC diff, laser scatter for NRBC/RET, impedance for RBC/PLT, cyanide-free HGB, 10.4-inch touchscreen, 200,000-result storage, and built-in printer. Supports venous, capillary, pre-diluted, and body fluid modes with auto-loader for streamlined, accurate blood profiling.
Description
5-Part Differentiation: Advanced White Blood Cell Subpopulation Analysis The Maccura F800 harnesses fluorescence nucleic acid staining and flow cytometry to achieve true 5-part WBC differentiation, enumerating neutrophils (NE# and NE%), eosinophils (EO# and EO%), basophils (BA# and BA%), monocytes (MO# and MO%), and lymphocytes (LY# and LY%). This technology, augmented by an independent basophil channel and NRBC detection, provides exceptional sensitivity for immature cells and naive leukocytes, enabling early identification of conditions like acute leukemias, parasitic infections, or bone marrow recovery, with enhanced accuracy in samples from oncology patients or those with high interference.
Parameters Measured: Evaluates up to 35 parameters (including 25+ reportable), covering comprehensive CBC, DIFF, and RET panels: WBC, NE#, EO#, BA#, MO#, LY#, NE%, EO%, BA%, MO%, LY%, NRBC#, NRBC%, RBC, HGB (through cyanide-free spectrophotometry for reduced toxicity), HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR, P-LCC, RET#, RET%, IRF (immature reticulocyte fraction), and HCT. Generates four histograms (WBC, BASO, RBC, PLT) plus a 2D scattergram and RET plot for in-depth morphological review, with AI-powered alarms for blasts, variants, inclusions, or reticulocyte maturity to flag anemias, thrombocytopenias, or erythropoietic disorders.
Sample Requirements: Utilizes a low 88 µL sample volume for efficient processing, suitable for routine adult testing or low-volume pediatric draws. Supports multiple modes—venous whole blood for standard workflows, capillary blood for rapid bedside analysis (e.g., fingerstick), pre-diluted for extended linearity, and body fluid for specialized CSF or serous fluid exams—ensuring broad applicability with minimal preparation and high sample integrity.
Throughput: Processes up to 100 CBC+DIFF samples per hour (or 17 SR tests), optimized for high-volume facilities like tertiary hospitals or reference labs handling 1,000+ tests daily. The integrated 50-tube auto-loader with barcode scanning enables walk-away automation, automatic rerun/reflect functions, and STAT priority queuing, slashing manual intervention and achieving first-result times under 1 minute for urgent cases.
Technology: Employs fluorescence staining + hydrodynamic focusing flow cytometry + tri-angle laser scatter for WBC/DIFF/NRBC/RET, electrical impedance for RBC/PLT, and cyanide-free colorimetric method for HGB to promote operator safety and environmental compliance. Independent multi-channel design reduces cross-talk, while advanced digital waveform analysis and specific nucleic acid binding deliver CVs <1% for critical metrics. Built-in quality assurance, including two-level QC and calibration traceability to ICSH/CLSI standards, ensures robust performance across diverse sample types, with enhanced sensitivity for low-concentration events like minimal residual disease.
User Interface and Storage: Outfitted with a 10.4-inch high-resolution color touchscreen featuring intuitive dashboards, real-time graphics, and multilingual support (up to 12 languages, including English, German, Japanese, and Chinese) for seamless global operation. Accommodates 200,000+ results with full datasets—parameters, plots, patient records, and QC histories—in a secure, searchable database. Integrated thermal printer produces tailored reports with multi-templates, while USB/LAN/RS232/Ethernet interfaces facilitate HL7 bi-directional LIS integration, remote access, and exports in PDF/XML/CSV for compliance with CAP/ISO 15189 audits.
Reagent System: Closed system optimized for Maccura’s proprietary, high-stability reagents (e.g., MAK-Fluoro Diff for staining, MAK-Diluent), with visual on-board management for up to 5 positions including dedicated dye and cleaner slots. Low-consumption design (up to 60% savings) and automated probe rinsing extend reagent life to 3 months, with real-time monitoring, low-stock alerts, and wider linearity (e.g., WBC up to 400 x 10^9/L) to minimize dilutions and operational costs in consolidated lab environments.
Dimensions and Portability: Ergonomic benchtop configuration at 650 × 850 × 750 mm (W × D × H) weighs 50 kg, with a curved, user-centric design for easy access and maintenance. Runs quietly (<60 dB) on AC 100–240V with ≤300 VA power, accommodating 10–35°C ambient temperatures and 30–85% humidity for versatile installation in core labs or integrated workstations.
- Throughput: Up to 100 samples/hour (CBC+DIFF); 17 samples/hour (SR).
- Detection Channel: Multi-channel (independent for WBC/DIFF/BASO/NRBC/RET, RBC/PLT).
- Detection Principle: Fluorescence staining + laser scatter + flow cytometry (WBC/DIFF/NRBC/RET), impedance method (RBC/PLT), cyanide-free colorimetric method (HGB).
- Detection Items: Up to 35 parameters including 5-part CBC+DIFF+RET (WBC, NE#, EO#, BA#, MO#, LY#, NE%, EO%, BA%, MO%, LY%, NRBC#, NRBC%, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR, P-LCC, RET#, RET%, IRF); 4 histograms + scattergram + RET plot; alarms for abnormal cells, blasts, reticulocytes.
- Built-in thermal printer, supports various types of printer. Multi-builtin print templates available.
- 200,000 sample results, including parameter, histogram, scattergram, RET plot, and patient information.
- Counting modes: Venous whole blood, capillary whole blood, pre-diluted, and body fluid.
