Emperor G76 Trolley Color Doppler Ultrasound System
The Emperor G76 is a high-performance trolley-based color Doppler ultrasound system offering advanced imaging technologies like ePure, eSCI, and eFCI for whole-body applications with AI-assisted measurements. Ideal for radiology, cardiology, OB/GYN, and vascular labs, it features a 21.5-inch HD monitor, ergonomic design, TDI and surface rendering, automatic IMT measurement, and wireless probe support for streamlined, high-resolution diagnostics.
Description
Design and Protection Mechanism: Trolley-Mounted Whole-Body Configuration The Emperor G76 is a robust, trolley-mounted color Doppler ultrasound system engineered for versatile, high-volume diagnostic imaging across abdominal, cardiac, obstetric, vascular, and small parts examinations in hospitals, clinics, and outpatient centers. Featuring a sleek, ergonomic design with a height-adjustable control panel and five-wheel base for effortless mobility, it weighs approximately 75 kg and includes gel warmers and a detachable transducer holder for user comfort. The IP54-rated housing resists dust and fluids, while the sealed keyboard and antimicrobial surfaces facilitate easy wipe-down with hospital-grade disinfectants, ensuring compliance with IEC 60601-1 safety standards and ISO 13485 quality management for reliable performance in sterile or high-traffic environments.
Performance and Imaging Technologies: Delivers exceptional image quality with proprietary ePure patented technology for speckle reduction and enhanced penetration, eSCI (space composite imaging) for multi-angle compounding, eFCI (frequency composite imaging) for broadband frequency fusion, and eSpeed adaptive optimization for real-time noise suppression. Supports Tissue Characterization for harmonic enhancement and 2D independent angle deflection for customizable views, achieving resolutions up to 0.1 mm in B-mode and Doppler velocities from 0.1–10 m/s with <5% CV. The system processes up to 30 cm/s frame rates for smooth 3D/4D rendering, ideal for dynamic assessments like fetal echocardiography or vascular flow mapping.
Probe and Accessibility: Accommodates up to 10 probe types (convex, linear, phased array, endocavity, biplane) with wireless connectivity options for cable-free operation up to 5 m. The articulating arm positions the 21.5-inch HD LED monitor (1920×1080 resolution) at eye level (adjustable 120–160 cm height), while the gel warmer (37°C) and backlit keyboard enhance workflow. The gel holder and cable management system minimize clutter, and the one-touch boot-up (under 30 seconds) supports rapid patient turnover in busy settings.
User Interface and Operational Features: Boasts a 21.5-inch high-definition touchscreen with gesture controls and customizable workflows, displaying real-time B/M/Color/PW/CW/Doppler modes alongside AI-assisted annotations. Multilingual support (up to 12 languages, including English and Chinese) and voice-activated commands streamline operation, with Anatomical M-Mode for curved cardiac views and TDI (tissue Doppler imaging) for myocardial velocity mapping. The built-in ultrasound assistant software offers self-learning modules and automatic intima-media thickness (IMT) measurement, while USB/LAN ports enable DICOM 3.0 integration for PACS/EMR connectivity and report export in PDF.
Sterilization and Maintenance: The non-porous control panel and probe holders clean with 70% IPA or quaternary ammonium solutions, with autoclavable probe sheaths available. The sealed fanless design reduces dust accumulation, and modular transducers detach for independent sterilization (134°C). Self-diagnostic routines at startup verify system integrity, with remote software updates via Ethernet; the LED backlight lasts >50,000 hours, and annual probe calibration ensures <2% drift, backed by a 3-year warranty.
Electrical and Environmental Specifications: Operates on AC 100–240V/50–60Hz at 300W with universal input and surge protection for global deployment. Rated for 10–40°C ambient temperatures and ≤80% RH, it includes EMI shielding (IEC 60601-1-2) to prevent interference with other devices. Low power consumption (<0.5 kWh/hour) and eco-mode extend operational efficiency.
Dimensions and Portability: Trolley dimensions: 530 × 770 × 1,450–1,650 mm (W × D × H) with a stable five-wheel base for smooth navigation through doorways. The foldable arm and quick-lock panels allow compact storage (reduces to 1.2 m height), with optional wheeled transport case for multi-site use.
- Throughput and Workflow: Processes 20–40 exams per shift with <1-minute mode switches, ideal for mixed OB/GYN and vascular caseloads.
- Detection and Monitoring: Multi-beamformer for real-time Doppler; logs 1,000 exams with AI flagging for anomalies.
- Detection Principle: Phased-array beamforming with composite imaging for enhanced resolution and penetration.
- Additional Features: eSurface rendering; auto-IMT; TDI for cardiology; wireless reporting.
- Data Storage: 500 GB SSD for 10,000+ images; DICOM export in multiple formats.
- Application Modes: Abdominal, cardiac, OB/GYN, vascular, small parts; supports 3D/4D and contrast imaging.
