Detroxan Air Spray by Detro

Description

Design and Protection Mechanism: Compact Portable Sprayer Configuration The Detroxan Air Spray by Detro is a user-friendly, handheld airborne disinfection device engineered for efficient, no-residue microbial inactivation across diverse environments, from operating rooms and ICUs to classrooms and hotel lobbies. Constructed with durable ABS plastic housing and a 45-degree angled nozzle for optimal spray coverage, it employs a high-pressure aerosol system to disperse ultrafine particles (<5 microns) that penetrate hard-to-reach surfaces and crevices without leaving wetness or traces. Safety interlocks include encrypted user login to prevent unauthorized access, a pause function for interruptions, and automatic shutoff post-cycle, complying with EN 17272 standards for surface and air disinfection while minimizing cross-contamination risks in high-traffic or infection-prone areas.

Disinfection Performance and Coverage: Achieves >99.9% log reduction against bacteria, viruses, fungi, and spores in 1–1000 m³ volumes, validated by accredited labs per EN 17272 for both 1 m³ and 30 m³ chambers. The programmable keypad allows customizable cycles (e.g., 3 minutes for 50 m³), with a 30-minute contact time for full efficacy before re-entry. Powered by a rechargeable lithium battery (up to 4 hours continuous use), it ensures consistent droplet ionization for broad-spectrum kill, including enveloped viruses like SARS-CoV-2, while the integrated particle filter captures incoming contaminants to maintain device hygiene.

Solution Compatibility and Application: Exclusively optimized for Detro San Air disinfectant—a ready-to-use, hydrogen peroxide (7.5%) and colloidal silver formulation that breaks down into water and oxygen, leaving no harmful residues. The 500 mL refillable reservoir supports up to 100 cycles per fill, with automatic priming to prevent clogs. Application requires pre-cleaning the space, then activating in an unmanned, sealed room; the fine mist ensures even distribution without surface damage, suitable for electronics, fabrics, and medical equipment.

User Interface and Operational Features: Features an intuitive LCD keypad display for easy program selection, volume input, and start/delay timing (up to 99 hours), with multilingual support (up to 6 languages, including English and Turkish) for global usability. Audible beeps and LED indicators signal cycle start/end, low battery, or errors, while the optional built-in thermal printer auto-logs up to 100 processes (date, time, volume, duration) for retrospective audits and compliance reporting. The ergonomic pistol-grip design with trigger lock enhances portability and precision during manual spot treatments.

Sterilization and Maintenance: The self-cleaning nozzle and particle filter (replaceable every 500 cycles) prevent buildup, with a quick-rinse mode using water or mild detergent for post-use hygiene. The device’s sealed construction resists corrosion from disinfectants, and annual calibration via USB ensures ongoing accuracy; no tools required for reservoir access or filter swaps, backed by a 2-year warranty for reliable, low-maintenance operation in demanding protocols.

Electrical and Environmental Specifications: Operates on a 7.4V rechargeable Li-ion battery (charger included) with low power draw (<10W), featuring overcharge protection and runtime indicators. Rated for 5–40°C ambient temperatures and up to 85% RH, it includes IP54 splash resistance for versatile indoor/outdoor use, with eco-mode to extend battery life by 20%.

Dimensions and Portability: Slim profile of 250 × 150 × 100 mm (L × W × H) weighs 1.2 kg (empty), with a shoulder strap and carrying case for effortless transport between rooms or sites. The foldable handle and quick-refill port enable setup in <1 minute, fitting standard backpacks for mobile teams in hospitals or public health campaigns.

• Throughput and Workflow: Decontaminates 50 m³ in 3 minutes with 30-minute dwell, supporting 20–50 cycles per charge for daily facility rotations.
• Detection and Monitoring: Integrated sensors for spray volume and cycle completion; logs printable records for validation.
• Detection Principle: Aerosolized hydrogen peroxide + colloidal silver for oxidative microbial disruption, with <5-micron particles for penetration.
• Additional Features: Delayed start timer; pause/resume; compatible with test strips for efficacy verification; multi-template print logs.
• Data Storage: Onboard memory for 100 processes, exportable via printer or USB for digital archiving.
• Application Modes: Automated room fogging or manual surface spraying; unmanned operation for safety.
